Panasonic Attune Electrek Condenser Microphone WX-CM470

Attune HD Electric Microphone Model Number: WX-CM470

Product Overview: The Attune HD Electric Microphone (WX-CM470) features a black, plastic-molded finish and is designed for reliable audio performance in various environments. It operates within a temperature range of -20 °C to +50 °C (-4 °F to 122 °F).

Audio Specifications:

• Frequency Response: 100 Hz - 8000 Hz (-10 dB, Typical)

• Sensitivity: -10 dB (0 dB=1 V/Pa, 1 kHz, Typical)

Physical Dimensions & Weight:

• Dimensions (Metric): 94 mm x 56 mm x 42 mm (Excluding projections)

• Dimensions (Imperial): 3 45/64" (W) x 2 13/64" (H) x 1 21/32" (D) (Excluding projections)

• Mass: Approximately 81 g (0.18 lb)

Cable Specifications:

• Type: Two core shielded wire

• Length: Approximately 1000 mm (39 3/8")

• Outer Diameter: ø3 mm (ø0.11 inches)

• Inner Wire: AWG24

• Wiring Color Code: Red (+), White (-), Black (GND)

Finish:

• Plastic-molded, black
