CUSTOM AMERICA GENIUS ALL-IN-ONE + PRINTER 80mm 13.3" WIN SSD 128GB RAM 8GB J3455 win10 iot

POS OF AMERICA

Sale price $1,499.00 Regular price $1,687.00

CUSTOM AMERICA GENIUS ALL-IN-ONE + PRINTER 80mm 13.3" WIN SSD 128GB RAM 8GB J3455 win10 iot

All-in-One Windows® PC POS compact and with a refined design, equipped with a 80mm thermal printer, 13.3" wide LCD touch screen and WI-FI® connectivity. GENIUS 2.0 is the ideal solution for those who need superior performance in small spaces.

921LD080400L33

CHARACTERISTICS

  • Compact and with a refined design
  • Integrated 80 mm thermal printer
  • 13.3" wide LCD touch screen with 1366x768 resolution (300 cd/mq)
  • Wi-Fi® module
  • Supported O.S.: Windows® 10 IoT
  • ON/OFF button
  • Status LED
  • Paper compartment opening button

MARKETS

  • Retail
  • Entertainment & Hospitality
  • Lottery & Betting


TECHNICAL SHEET

Processor Intel® Celeron® J3455, 2.3 GHz
Memory RAM 8 GB
Hard Disk 128 GB su SSD mSATA
Display LCD 13.3" TFT backlit
Resolution 1366 x 768
Aspect ratio 16:9 (WXGA)
Brightness 300cd/m2
Touch screen Capacitive
Wi-Fi Standard 802.11 b/g/n 2.4G single channels
Operating system Windows® 10 IoT
Software tools Custom Windows API
Sensors Paper presence
Paper compartment cover opening
Printhead temperature
Low paper end
Cutter position
I/O 4 x USB 3.0 port
1 x Ethernet/RJ45 port
1 x HDMI port
1 x Cash drawer (RJ12) port
1 x COM RS232 (RJ12) port
Power supply from 100 Vac to 240 Vac
Dimension 266.4 mm (W) x 337.5 mm (L) x 270.5 mm (H)
Weight 4,5 Kg

INTEGRATED THERMAL PRINTER
Resolution 203dpi (8 dot/mm)
Printing method Thermal with fixed head (8 dot/mm)
Printing speed 140 mm/s
Paper width 80 mm
Paper weight from 55 to 60 g/m²
Paper thickness 63 μm
External roll diameter max 80 mm
