POSBANK EDGE 1560 15.6” N97 8GB 128GB WINDOWS 11
DGE was born with an ultra-slim design and a fanless structure. It supports both Android and Windows operating systems with the latest CPUs, supporting GMS authentication and MDM solutions. It boasts a slimmer and more edgy design and is a POS device loved by various industries such as restaurants and retail.
-
-
Processors[EDGE AN-1560]
Intel® Processor N97 6M Cache, up to 3.60 GHz
Chipset[EDGE AN-1560]
Intel Alder Lake-N
- -
Memory[EDGE AN-1560]
4GB Standard, DDR4 3200 MT/s, Socket 1 x SODIMM (Max. 16GB)
-
Storage[EDGE AN-1560]
1. Form Factor
NVME M.2 2242-D2-M (No capacity limit.)
2. Mountable quantity:
Up to 1 units can be installed.
* Factory Default : NVMe M.2 2242 128GB x 1
[EDGE A2-1560]
eMMC 32GB, On-board (Max.64GB) -
RAID-
-
Operating Systems[EDGE AN-1560]
Windows 10 version 21H1 or higher
-
Software-
-
Printer-
-
AudioHD Audio Codec
-
- Display
-
-
Type15.6" TFT LCD, LED Backlight (eDP Interface)
-
Resolution1920 x 1080
-
Brightness300 cd/m² (option) / 350 cd/m²
-
View Angle (U/D/R/L)-
-
TouchscreenProjected Capacitive Touch
-
- Interface
-
-
DisplayDisplay port x 1 (MiniDP)
-
USBRear 4 (USB 3.0 x 2,USB 2.0 x 2)
Internal 1 (Reserved for MSR/SCR/i-Button) -
PS/23 (COM1, COM2 RJ-45, Full Signal)
(COM3 reserved MSR/SCR, Tx/Rx only)
(COM4 reserved CDP, Tx/Rx only) -
SerialRJ-12 (Integrated circuit GPIO)
-
CashDrawer Port-
-
LANGigabit Ethernet x 1 (RJ-45)
-
AudioLine-out x 1
-
Power DC-INDIN 4 Pin Jack
-
MSR-
-
VGA-
-
HDMI-
-
SD Card Slot-
-
Extension Slot-
-
OTG-
-
- Power
-
-
Power Supply[EDGE AN-1560]]
Adaptor 12V, 5A(C-Type Plug)
[EDGE A2-1560]
Adaptor 12V, 5A
-
- Physical & Environmental
-
-
Operating Temperature0 ℃ ~ 60 ℃ at 10% to 90% Humidity
-
Storage Temperature-20 ℃ ~ 80 ℃ at 10% to 90% Humidity
-
Dimensions (W x D x H)W)367 x (D)180 x (H)289 (mm), (W)14.4 x (D)7 x (H)11.4 (in)
-
Packing Dimensions (W x D x H)(W)455 x (D)163 x (H)308 (mm), (W)17.9 x (D)6.4 x (H)12.1 (in)
-
Net Weight2,950g, 6.5 lbs
-
Packing Weight5,000g, 11 lbs
-
CertificationCE, FCC, KC
-
ColorMatte Dark Grey, Matte White
-
